The EASY-Display
88 Operating Manual
Keyboard range
Here you specify whether the sound should play on the entire manual or only in a special area. Press
"Keyboard Range" once and the display keyboard for the upper or lower manual will appear.
You can easily enter the keyboard range via the corresponding manual. Press first the deepest and then the
highest button of the desired range. The area you entered is displayed on the display keyboard and the input
window disappears after a moment.
Note: Please note that this is not a split point where the manual is divided into two areas. You can set a
separate keyboard ranges for each selector and distribute the sounds individually on the manuals.
ATTENTION: When entering the play area by pressing the lowest and highest key, please note the following:
If the lowest note for the desired play area is above the center of the keyboard, you must first press a key
below the center. You have to approach the desired note from below. The easiest way is to make a glissando
from the very bottom and stop at the desired note.
Volume
View the volume control that is appropriate for the
manual. You can also use the upper 1 to 3, lower 1
to 3 and pedal drawbars to adjust the volume.
Panorama, Reverb 1 and 2, Chorus and Echo
The Panorama knob can be used to adjust the
position of the sound in the stereo image. With the
controls Reverb 1 and 2, Chorus and Echo, the
effect parts (Send) are set for this sound.
For example, if you want more reverb on this sound,
slide the Reverb 1 or 2 slider further up. In the
factory setting, reverb 1 is occupied with a "normal"
reverb program and the reverb 2 with a longer Hall
program.
