Xerox 4595 - Output Orientation

Xerox 4595 Copier/Printer User Guide
2-77
2. Copy
 Paper Supply
Select paper tray for loading index paper.
NOTE: Paper Supply icon does not display if Off is selected.
When loading the tab paper in Tray 5 (Bypass), load the
paper with the side to be copied facing up and with the
edge opposite to the tab to be fed first. When loading the
tab paper in tray 3 or 4, load the paper with the side to be
copied facing down and with the edge opposite to the tab
aligning to the left side of the tray.
You can load the tab paper in tray 3 to 4 only when
selecting Tabbed Stock 1 105-216g/m2.
 Tab Stock Size
Select the size of index paper.
 Tab Stock Type
Select the quality of index paper.
Output Orientation
You can select whether copies should be output facing up or
down.
1. From the Output Format tab, select Output Orientation.
2. Select any item.
3. Select Save to keep your choice.
