Xerox 4595 Copier/Printer User Guide
7-10
7. Paper and Other Media
2. Load the paper, aligning to the front side of the tray.
Load tab paper
Following describes the procedure for loading a tab paper in
Trays 3 to 4, Tray 5 (Bypass) and the Post-Process Inserter.
Load tab paper in trays 3 and 4
1. Pull out the tray towards you until it stops.
WARNING: When pulling out the paper tray, do it slowly. If pulled
out with too much force, the tray can hit and injure your knees.
2. Load and align the edge of the tab paper against the right
edge of the tray with the side to be copied or printed on
facing down.
3. Move the two paper guide levers while holding their grips so
To Next Page
