1. Product overview
No. Component Function
1 DADF Duplex Automatic Document Feeder
2 Document cover Holds a document in place on the document glass.
3 Control Panel The Control Panel consists of the Touch Screen, Pathway buttons, Feature
buttons and Numeric keypad. Refer to “Control Panel” on page 1-9.
4 Document glass Place a document here in order to copy it.
5 Power switch Switches on/off the machine power.
6 Front cover Open this cover to clear paper jams and to replace the waste toner bottles.
7 Left Cover Open this cover to replace the toner cartridge.
8 Tray 1, 2, 3, 4 Contains the media used for copy or print output.
9 Locking casters Locks the wheels of the machine. Lock these casters after moving the
machine to its installation site.
10 Bottom left cover Open this cover to remove paper jams.
11 Front cover for the
optional Trays 6
and 7
Open this cover to access the bottom left cover.This cover and the trays 6 and
7 are part of the optional High Capacity Feeder (HCF).
12a Tray 6, 7 (optional
HCF)
Contains the media used for copy or print output.
12b Tray 6 (optional
OHCF)
Alternative to the 2-drawer HCF, the optional Oversized High Capacity Feeder
(OHCF) feeds oversized stock up to 13 x 19 in/SRA3 paper.
13 Tray 5 (Bypass) Load nonstandard paper, such as heavy stock or other special media, that
cannot be loaded in trays 1-4.
