Xerox 4595 Copier/Printer User Guide
7-17
7. Paper and Other Media
4. Load and align the paper stack in the lower right corner of
the tray as shown below.
NOTE: Do not load paper exceeding the maximum fill line. Doing
so might cause paper jams or machine malfunctions.
5. Slide both paper guides to just touch the edges of the paper
stack.
NOTE: Position the paper guides correctly to match the paper
size. If the position of the paper guide is not correct, the paper
may not be fed properly and paper jams may occur.
CAUTION: For paper heavier than 256 gsm, slide both Paper
Weight Switches to the heavier weight position (257 - 300 gsm).
Failure to do so may result in paper jams.
6. Move both Paper Weight Switches to their appropriate
positions.
7. Push the tray in gently until it comes to a stop.
NOTE: When the loaded tray is closed, the tray position is
automatically adjusted in the front/back direction based on the
paper size.
To Next Page
