Xerox 4595 Copier/Printer User Guide
11-57
11. Problem Solving
Paper Jams inside body
The following section describes how to remedy paper jams that
occur at the transfer module of the body.
1. Make sure that the machine has stopped before opening the
front cover.
2. Turn the green lever at the center of the transfer module to the
right until it is in the horizontal position and then pull the
transfer module out to the end.
3. Lift up the lever 2b to remove the jammed paper. Turn the
knob 2b to remove the jammed paper as necessary.
WARNING: Never touch a labeled area
(found on the fuser unit or nearby) indicating
“High Temperature” and “Caution.” Contact
can lead to burns.
