Xerox 4595 Copier/Printer User Guide
11-59
11. Problem Solving
7. Shift the lever 3b on the right of the fuser unit as necessary
and then remove the jammed paper.
KEY POINT: If the jammed paper remains inside and it is difficult
to remove, pull out the duplex module after returning the transfer
module to the original position. Then try again.
8. Insert the transfer module completely and turn the green lever
2 to the left.
NOTE: If the lever cannot be turn, pull the transfer module to the
middle and insert it again.
9. Close the front cover.
NOTE: A message will be displayed and the machine will not
operate if the front cover is even slightly open.
