Safety
WorkCentre 7120 Multifunction Printer
User Guide
12
Electrical Safety
WARNINGS:
• Do not push objects, including paper clips or staples, into slots or openings on the printer.
Making contact with a voltage point or shorting out a part could result in fire or electrical shock.
• Do not remove the covers or guards that are fastened with screws unless you are installing
optional equipment and are specifically instructed to do so. Power should be OFF when
performing these installations. Disconnect the power cord when removing covers and guards
for installing optional equipment. Except for user-installable options, there are no parts that
you can maintain or service behind these covers.
The printer must be turned off before removing the power cord. For instructions on turning the printer
off, see Turning the Printer Off on page 40.
The following are hazards to your safety:
• The power cord is damaged or frayed.
• Liquid is spilled into the printer.
• The printer is exposed to water.
If any of these conditions occur, do the following:
1. Turn off the printer immediately.
2. Disconnect the power cord from the electrical outlet.
3. Call an authorized service representative.
Electrical Supply
The printer must be operated from the type of electrical supply indicated on the printer’s data plate
label. If you are not sure if your electrical supply meets the requirements, please consult a licensed
electrician for advice.
WARNING: This printer must be connected to a protective earth circuit. This printer is supplied
with a plug that has a protective earth pin. This plug will only fit into an earthed electrical outlet.
This is a safety feature. If you are unable to insert the plug into the outlet, contact a licensed
electrician to replace the outlet.
Power Cord
• Always connect equipment to a correctly grounded power outlet. If in doubt, have the outlet
checked by a qualified electrician.
• Use the power cord supplied with your printer.
• Do not use a ground adapter plug to connect the printer to an electrical outlet that does not have
a ground connection terminal.
• Do not use an extension cord or power strip.

Xerox WORKCENTRE 7120 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	13 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A3)	11 ppm
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, TIFF
Maximum scan area	216 x 279 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.5 s
Scan file formats	PDF, XPS
Weight (imperial)	251 lbs
Custom media sizes	5.5''x 7.2'' - 11.7''x 17''
Dimensions (WxDxH)	585 x 640 x 1132 mm
Power requirements	100 - 240V, 50/60Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	148 x 210mm - 297 x 420mm
Media weight (tray 2)	60 - 256 gsm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows XP SP1 32/64-bit Windows Server 2003 32/64-bit Windows Server 2008 32/64-bit Windows Vista 32/64-bit Windows 7 32/64-bit Mac OS v10.4+ AIX 5 v5.3 HP UX 11.0, 11i v2 Solaris 8, 9, 10 Linux FedoraCore 1, 5 RedHat Enterprise Linux 4 SUSE 10/11
Dimensions (W x D x H) (imperial)	23 x 25.2 x 44.6 \
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	2130 sheets
Total number of input trays	5
Auto document feeder (ADF) input capacity	110 sheets
Internal storage capacity	80 GB
Sound power level (standby)	16 dB
Sound pressure level (printing)	52 dB
Display	-
Market positioning	Business
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Supported network protocols (IPv4)	SMTP, S/MIME, POP3, HTTP/HTTPS, LPR/LPD, IPv4/IPv6, Bindery, NDS IPX/SPX, NDPS/NEPS, EtherTalk, NetBEUI, MVNoIP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	119 W
Power consumption (average operating)	578 W
Sustainability certificates	ENERGY STAR
Certification	FCC, CB, ISO
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
