Maintenance
WorkCentre 7120 Multifunction Printer
User Guide
171
Main Staple Replacement for Office Finisher LX
WARNING: Do not perform this procedure when the printer is copying or printing.
1. Open the finisher front cover.
2. The staple cartridge is located inside the finisher cabinet. Pull the staple unit toward you until it stops.
3. Push the staple unit to the right.
4. Remove the staple cartridge by gripping the orange tab at R1 and pulling it firmly toward you.
