Xerox WORKCENTRE 7120 User Manual

Regulatory Information
WorkCentre 7120 Multifunction Printer
User Guide
223
Repairs to certified equipment should be coordinated by a representative designated by the supplier.
Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give
the telecommunications company cause to request the user to disconnect the equipment.
Users should make sure for their own protection that the electrical ground connections of the power
utility, telephone lines and internal metallic water pipe systems, if present, are connected together.
This precaution may be particularly important in rural areas.
WARNING: Users should not attempt to make such connections themselves, but should contact
the appropriate electric inspection authority, or electrician, as appropriate.
The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the
maximum number of terminals allowed to be connected to a telephone interface. The termination on
an interface may consist of any combination of devices subject only to the requirement that the sum
of the Ringer Equivalent Numbers of all of the devices does not exceed 5. For the Canadian REN value,
please see the label on the equipment.
Europe
Radio Equipment & Telecommunications Terminal Equipment Directive
The Facsimile has been approved in accordance with the Council Decision 1999/5/EC for pan-European
single terminal connection to the public switched telephone network (PSTN). However, due to
differences between the individual PSTNs provided in different countries, the approval does not, of
itself, give an unconditional assurance of successful operation on every PSTN network terminal point.
In the event of a problem you should contact your authorized local dealer in the first instance.
This product has been tested to and is compliant with ES 203 021-1, -2, -3, a specification for terminal
equipment for use on analogue-switched telephone networks in the European Economic Area. This
product provides an user-adjustable setting of the country code. Refer to the customer documentation
for this procedure. Country codes should be set prior to connecting this product to the network.
Note: Although this product can use either loop disconnect (pulse) or DTMF (tone) signaling, it is
recommended that it is set to use DTMF signaling. DTMF signaling provides reliable and faster call
setup. Modification of this product, connection to external control software or to external control
apparatus not authorized by Xerox, will invalidate its certification.
South Africa
This modem must be used in conjunction with an approved surge protection device.

Xerox WORKCENTRE 7120 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	13 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A3)	11 ppm
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, TIFF
Maximum scan area	216 x 279 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.5 s
Scan file formats	PDF, XPS
Weight (imperial)	251 lbs
Custom media sizes	5.5''x 7.2'' - 11.7''x 17''
Dimensions (WxDxH)	585 x 640 x 1132 mm
Power requirements	100 - 240V, 50/60Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	148 x 210mm - 297 x 420mm
Media weight (tray 2)	60 - 256 gsm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows XP SP1 32/64-bit Windows Server 2003 32/64-bit Windows Server 2008 32/64-bit Windows Vista 32/64-bit Windows 7 32/64-bit Mac OS v10.4+ AIX 5 v5.3 HP UX 11.0, 11i v2 Solaris 8, 9, 10 Linux FedoraCore 1, 5 RedHat Enterprise Linux 4 SUSE 10/11
Dimensions (W x D x H) (imperial)	23 x 25.2 x 44.6 \
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	2130 sheets
Total number of input trays	5
Auto document feeder (ADF) input capacity	110 sheets
Internal storage capacity	80 GB
Sound power level (standby)	16 dB
Sound pressure level (printing)	52 dB
Display	-
Market positioning	Business
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Supported network protocols (IPv4)	SMTP, S/MIME, POP3, HTTP/HTTPS, LPR/LPD, IPv4/IPv6, Bindery, NDS IPX/SPX, NDPS/NEPS, EtherTalk, NetBEUI, MVNoIP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	119 W
Power consumption (average operating)	578 W
Sustainability certificates	ENERGY STAR
Certification	FCC, CB, ISO
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
