Xerox WORKCENTRE 7120 User Manual

Installation and Setup
WorkCentre 7120 Multifunction Printer
User Guide
40
Turning the Printer Off
Press the power switch, visible on the lower center tray, to the off position to turn the printer off.
Internal processing takes place before the printer shuts off.
Notes:
• Wait five seconds after any active job completes before turning the printer off.
• When the optional Office Finisher LX is attached, the power switch is located behind a
clear plastic door in the finisher transport cover/center tray.
Turning Main Power Off
Main printer power is controlled by the main power switch. Main power should be left on for normal
printer operation and should only be turned off when connecting a cable to the printer or when
cleaning the printer.
CAUTIONS:
• Do not switch the main power off while a job is being processed or while the Energy Saver
button is blinking. This may cause damage to the printer's internal hard drive or cause a
printer malfunction.
• Switch the main power off before unplugging the power cord. Unplugging the power cord
with the main power on may damage the printer's internal hard drive or cause a
printer malfunction.
• Do not switch main power off immediately after switching it on. Doing so may damage the
printer’s internal hard drive or cause a printer malfunction.
• Do not switch main power off immediately after switching the power switch off. Doing so
may damage the printer’s internal hard drive or cause a printer malfunction. Wait 10 seconds
after the touch screen goes dark before turning off main power.
1. Make sure the power switch, visible on the lower center tray, is in the off position.
Power switch Power switch with optional Office Finisher LX
wc7120-013
wc7120-012

Xerox WORKCENTRE 7120 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	13 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A3)	11 ppm
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, TIFF
Maximum scan area	216 x 279 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.5 s
Scan file formats	PDF, XPS
Weight (imperial)	251 lbs
Custom media sizes	5.5''x 7.2'' - 11.7''x 17''
Dimensions (WxDxH)	585 x 640 x 1132 mm
Power requirements	100 - 240V, 50/60Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	148 x 210mm - 297 x 420mm
Media weight (tray 2)	60 - 256 gsm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows XP SP1 32/64-bit Windows Server 2003 32/64-bit Windows Server 2008 32/64-bit Windows Vista 32/64-bit Windows 7 32/64-bit Mac OS v10.4+ AIX 5 v5.3 HP UX 11.0, 11i v2 Solaris 8, 9, 10 Linux FedoraCore 1, 5 RedHat Enterprise Linux 4 SUSE 10/11
Dimensions (W x D x H) (imperial)	23 x 25.2 x 44.6 \
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	2130 sheets
Total number of input trays	5
Auto document feeder (ADF) input capacity	110 sheets
Internal storage capacity	80 GB
Sound power level (standby)	16 dB
Sound pressure level (printing)	52 dB
Display	-
Market positioning	Business
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Supported network protocols (IPv4)	SMTP, S/MIME, POP3, HTTP/HTTPS, LPR/LPD, IPv4/IPv6, Bindery, NDS IPX/SPX, NDPS/NEPS, EtherTalk, NetBEUI, MVNoIP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	119 W
Power consumption (average operating)	578 W
Sustainability certificates	ENERGY STAR
Certification	FCC, CB, ISO
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
