Xerox WORKCENTRE 7120 User Manual

Faxing
WorkCentre 7120 Multifunction Printer
User Guide
154
More Fax Options
Further optional fax settings are provided. To adjust these settings:
1. On the touch screen, touch Fax, then touch the More Fax Options tab.
2. Touch the desired option, touch the desired settings, then touch Save.
Note: These settings are not available for Server Fax.
Internet Fax Options
Additional Internet Fax options are provided. To make these settings:
1. On the touch screen, touch Internet Fax, then touch the Internet Fax Options tab.
2. Touch the desired option, touch the desired settings, then touch Save.
Note: For details, see the System Administrator Guide at www.xerox.com/office/WC7120docs.
Option Values
Remote Polling Off, Poll a Remote Device (retrieve files stored on a remote fax machine by
using the Remote Folder feature)
Store for Polling Off, Store for Free Polling and Store for Secure Polling (fax documents stored
in the printer are made available for remote polling by enabling Free Polling
or Secure Local Polling, then touching the folder and file)
On-Hook (Manual
Send/Receive)
Manual Send: touch On-Hook, touch Manual Send, then use the touch
screen keyboard to enter destination and passcode
Manual Receive: touch On-Hook, touch Manual Receive, then press green
Start button
Option Values
Acknowledgement Report Confirmation Options: Off, print report after each fax transmission
Read Receipts: Off, request read receipt from recipient’s fax server
Internet Fax Profile TIFF-S: use for A4, 210 x 297 mm (8.5 x 11 in.) originals with Standard or
Fine Resolution
TIFF-F or TIFF-J: use for A3, 297 x 420 mm (11 x 17 in.) originals with
Superfine Resolution
Pages per Side Off, On (touch plus or minus buttons (+/–) to set quantity)
Starting Rate G3 Auto, Forced 4800 bps, G4 Auto
Transmission Header Text Off, Display Header

Xerox WORKCENTRE 7120 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	13 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A3)	11 ppm
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, TIFF
Maximum scan area	216 x 279 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.5 s
Scan file formats	PDF, XPS
Weight (imperial)	251 lbs
Custom media sizes	5.5''x 7.2'' - 11.7''x 17''
Dimensions (WxDxH)	585 x 640 x 1132 mm
Power requirements	100 - 240V, 50/60Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	148 x 210mm - 297 x 420mm
Media weight (tray 2)	60 - 256 gsm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows XP SP1 32/64-bit Windows Server 2003 32/64-bit Windows Server 2008 32/64-bit Windows Vista 32/64-bit Windows 7 32/64-bit Mac OS v10.4+ AIX 5 v5.3 HP UX 11.0, 11i v2 Solaris 8, 9, 10 Linux FedoraCore 1, 5 RedHat Enterprise Linux 4 SUSE 10/11
Dimensions (W x D x H) (imperial)	23 x 25.2 x 44.6 \
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	2130 sheets
Total number of input trays	5
Auto document feeder (ADF) input capacity	110 sheets
Internal storage capacity	80 GB
Sound power level (standby)	16 dB
Sound pressure level (printing)	52 dB
Display	-
Market positioning	Business
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Supported network protocols (IPv4)	SMTP, S/MIME, POP3, HTTP/HTTPS, LPR/LPD, IPv4/IPv6, Bindery, NDS IPX/SPX, NDPS/NEPS, EtherTalk, NetBEUI, MVNoIP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	119 W
Power consumption (average operating)	578 W
Sustainability certificates	ENERGY STAR
Certification	FCC, CB, ISO
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
