Troubleshooting
WorkCentre 7120 Multifunction Printer
User Guide
182
Clearing Paper Jams in Document Feeder
1. Lift the lever, then open the document feeder top cover until it comes to a stop.
2. If the paper is not jammed in the document feeder, pull it out in the direction shown.
3. If the message on the touch screen instructs you to turn the knob, turn it to eject the paper. Pull
gently on the paper to remove it from the document feeder.
4. If the message on the touch screen instructs you to open the inner cover, lift the green handle up,
then open the inner cover.
To Next Page
