Xerox WORKCENTRE 7120 User Manual

Printing
WorkCentre 7120 Multifunction Printer
User Guide
92
Charge Print
When this feature is enabled, only the print jobs of authenticated users can be printed.
This feature must be configured by the System Administrator. For details, see the
System Administrator Guide at www.xerox.com/office/WC7120docs.
To print using this feature:
1. Print the job from your application.
2. On the printer control panel, press the Log In/Out button.
3. Using the touch screen keyboard, enter the user identification, then touch Enter.
4. If required, enter the passcode, then touch Enter.
5. Press the Job Status button, touch the Secure Print Jobs & More tab, then touch Charge Print.
6. Touch the desired user, then touch Job List.
7. If required, enter the passcode, then touch Confirm.
8. Touch the job to be printed or deleted.
9. If desired, specify the number of print sets using the alphanumeric keypad, then touch Print.
After printing, the job is deleted.
10. To delete the job without printing, touch Delete.
CAUTION: Once deleted, a job cannot be restored.
11. When finished, press the Log In/Out button, then touch Logout.
Saving a Print Job to the Printer
The Store File in Folder job type stores a print job in a folder in the printer. You can print the job from
the printer control panel. The job is not automatically deleted after printing, but it can be manually
deleted at the printer control panel.
Windows
1. In the printer driver, click Paper/Output, click the Job Type menu, then click Store File in Folder.
2. In the Store File in Folder window, do one of the following:
• Click the arrow to the right of Job Name, then click Use Document Name.
• Delete the text in the Job Name field, then type a job name.
3. To select a Folder Number, do one of the following:
• Click the arrow to the right of Folder Number, then click a folder number in the list.
• Delete the text in the Folder Number field, then type a folder number.
4. To create a Secure Saved Job:
a. Select the Secure Saved Job check box.
b. Type and confirm a 1- to 20-digit passcode.
5. Click OK three times.
The job is stored in the printer.

Xerox WORKCENTRE 7120 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	13 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A3)	11 ppm
Print speed (black, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Page description languages	PCL 6, TIFF
Maximum scan area	216 x 279 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	6.5 s
Scan file formats	PDF, XPS
Weight (imperial)	251 lbs
Custom media sizes	5.5''x 7.2'' - 11.7''x 17''
Dimensions (WxDxH)	585 x 640 x 1132 mm
Power requirements	100 - 240V, 50/60Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	148 x 210mm - 297 x 420mm
Media weight (tray 2)	60 - 256 gsm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows XP SP1 32/64-bit Windows Server 2003 32/64-bit Windows Server 2008 32/64-bit Windows Vista 32/64-bit Windows 7 32/64-bit Mac OS v10.4+ AIX 5 v5.3 HP UX 11.0, 11i v2 Solaris 8, 9, 10 Linux FedoraCore 1, 5 RedHat Enterprise Linux 4 SUSE 10/11
Dimensions (W x D x H) (imperial)	23 x 25.2 x 44.6 \
Total input capacity	520 sheets
Total output capacity	250 sheets
Maximum input capacity	2130 sheets
Total number of input trays	5
Auto document feeder (ADF) input capacity	110 sheets
Internal storage capacity	80 GB
Sound power level (standby)	16 dB
Sound pressure level (printing)	52 dB
Display	-
Market positioning	Business
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4, B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Supported network protocols (IPv4)	SMTP, S/MIME, POP3, HTTP/HTTPS, LPR/LPD, IPv4/IPv6, Bindery, NDS IPX/SPX, NDPS/NEPS, EtherTalk, NetBEUI, MVNoIP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	119 W
Power consumption (average operating)	578 W
Sustainability certificates	ENERGY STAR
Certification	FCC, CB, ISO
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
