December 2006
6-17
WorkCentre M20, 4118, FaxCentre 2218 Family
GP 3
General Procedures and Information
WorkCentre M20i
Refer to Figure 3 for the WorkCentre M20i service mode flowchart. The flowchart only shows
the upper two levels of options that are available. Refer to Table 3 for the complete list of
options.
Table 2 M20 service mode settings
Function Item Option
Machine Setup Tray 1 Size Letter / A4 / Legal / Folio
Tray 2 Size Letter / A4 / Legal / Folio
Bypass Size Letter / A4 / Legal / Folio / A5/ Statement
Power Save On / Off
Machine Timeout 15 / 30 / 60 / 180 / Off
Alarm Sound On / Off
Key Sound On / Off
Language English / French / German / Italian / Spanish /
Portuguese / Dutch / Danish / Finnish / Nor-
wegian / Swedish / Russian
Localisation Inch / MM
USB Mode Fast / Slow
Date & Time 00-00-0000 / 00:00 (AM)
Clock Mode 12/ 24 Hours
Toner Save On / Off
System Admin
Tools
Password Protect No / Yes
Department Codes Change / Delete
Auxiliary Access On / Off
Email Setup SMTP Server Setup / Auth User Setup / Auto
Send to Self / Guest User Access / Default
From / Default Subject / LDAP Server Setup
Change Passcode
Clear Memory System Data / Email Address Book / Email
TX History / Clear All Memory (GP 5)
Maintenance (GP
6)
Serial Number / Clean Drum / New Drum /
Billing Counters / Notify Toner Low / Switch
Test / DRAM Test / ROM Test / Pattern Test /
Shading Test / Engine Test / Flash Upgrade /
Sys Admin Passcode
Reports (GP 7) System Data / Email TX Report / Billing/
Counters / Connect Page / Auth Fail Report /
Print All Reports (includes Help List)
To Next Page
