Xerox WorkCentre M20 - IQ1 Image Quality Entry RAP

December 2006
3-3
WorkCentre M20, 4118, FaxCentre 2218 Family
IQ1
Image Quality
IQ1 Image Quality Entry RAP
Use this RAP to determine the source of an image quality problem.
Initial Actions
• Check the condition of the paper. Do not use incorrectly cut paper, damp paper, paper
with rough edges, badly drilled paper, paper with wrapper wax or glue. Paper and media
should be stored flat, enclosed in wrappers, in a cool dry environment.
• Check that the paper is within specifications. Refer to GP 22 Paper and Media Specifica-
tions.
• Check that paper tray guides are set to the correct paper size.
• Check the document guides on the DADF or ADF.
• Check the original documents for defects.
• Ensure that the image adjustment mode selections are those used by the customer.
Procedure
If necessary, refer to IQ1 Internal Test Patterns for:
• A description of image quality defects.
• The optimum test pattern to be used to diagnose the defect.
• An example of all internal test patterns.
If possible, use the customer job to recreate the image quality problem.
Go to GP 3, Service Mode Entry. Scroll to System Admin Tools/Maintenance/Pattern Test.
Select a suitable test pattern. Press Enter. Go to the relevant RAP:
• IQ2 Blank Copies RAP
• IQ3 Black Copies From the Scanner RAP
• IQ4 Blurred Image From the Scanner RAP
• IQ5 Vertical Lines or Bands RAP
• IQ6 Vertical White Lines RAP
• IQ7 Light Image RAP
• IQ8 Dark Image RAP
• IQ9 Background RAP
• IQ10 Ghost Images RAP
• IQ11 Stains on Back of Paper RAP
• IQ12 Poor Fusing RAP
• IQ13 Partial Blank Image (Not Periodic) RAP
• IQ14 Partial Blank Image (Periodic) RAP
• IQ15 Different Image Density (Left and Right) RAP
• IQ16 Horizontal Bands RAP
• IQ17 Periodic Printing Defects Check RAP
• IQ18 Print Damage RAP
• IQ19 DADF Lead Edge Offset RAP (M20F/2218)
• IQ20 Poor Side Edge Registration RAP
• IQ21 Spots or Marks RAP
IQ1 Internal Test Patterns
Table 1 defines the image defect, gives a description of the defect and identifies the optimum
test pattern to be used.
Table 2 describes the test patterns and the purpose for which they should be used to identify
image quality defects.
Table 1 Image quality defects
Image quality
defect Description of defect
Optimum
internal test
pattern
Background Uniform darkening across all the non print areas 1
Bands Grey to dark in the light or non-image areas of the print in the
process direction or across the process direction. See also
narrow bands.
1
Beads on print Developer beads in the light or non-image areas of the print. 1, 6, 7
Black image A print that is black or grey all over, but has no visible image
of the original document.
1, 6, 7
Blank image No visible image. 1, 6, 7
Blurred image Part or whole of the image has the appearance of being out
of focus.
1, 6, 7
Dark prints Very dark background with a visible image. 1, 6, 7
Deletions Areas of the image missing from the print. Deletions may be
in the form of white spots, marks, lines, or whole areas of
toner missing from the print.
1, 5
Displaced and
fragmented
Distorted images, part images and missing images (scram-
bled images). Displaced images.
1
Light image The image is visible on the print, but with insufficient solid
area density.
1
Lines Black or white lines across the process direction or in the pro-
cess direction. See also the description, displaced and frag-
mented image.
1, 6
Magnification At 100% magnification the printed image differs from the size
of the image on the original document.
6
Marks Dark marks in the non-image areas of the print. 1, 6
Misregistration The image on the paper is Misregistration. 6
Narrow Bands Bands across the process direction visible in halftone areas. 1, 3, 4
Non uniformity Variation in image quality and density across the print. See
also uneven density.
3, 4
Offsetting A previous image that was not removed from the fuser roll
during the cleaning cycle. The image is repeated at regular
intervals.
1, 4
Part images
and missing
images
Incomplete or missing images. 1
Print damage Creases, curl, cuts, folds, wrinkles, or embossed marks are
visible on the print.
1, 2, 3, 4, 5, 6,
7
