December 2006
3-21
WorkCentre M20, 4118, FaxCentre 2218 Family
IQS 1
Image Quality
IQS 1 Solid Area Density
Documents
Test pattern: 82P524 and the solid area density scales, 82E8230 (SIR 542.00) or 82P448 (SIR
494.00).
Specification
Make a copy of the test pattern. Compare the copy with the solid area density scale. The den-
sity of the 1.0 areas on the copy of the test pattern, must be as dark or darker than the 0.8 ref-
erence on the solid area density scale. Refer to Figure 1.
Figure 1 Solid area density
