Xerox WorkCentre M20 - GP 10 General Disassembly Precautions; GP 11 Machine Specifications

December 2006
6-32
WorkCentre M20, 4118, FaxCentre 2218 Family
GP 10, GP 11
General Procedures and Information
GP 10 General Disassembly Precautions
Purpose
Use this procedure when disassembling and reassembling components.
Procedure
The close proximity of cables to moving parts makes proper routing essential. If components
are removed, any cables disturbed by the procedure must be restored as close as possible to
their original positions. Before removing any component from the machine, note the cable rout-
ing that will be affected.
Whenever servicing the machine, perform the following:
1. Check to verify that documents are not stored in memory.
2. Unplug the power cord.
3. Use a flat and clean surface.
4. Only install authorized components.
5. Do not forcibly remove plastic components.
6. Ensure all components are in their correct position.
GP 11 Machine Specifications
Specifications are correct at the time of publication. Machine specifications are subject to
change without notice. Refer to the relevant section:
• M20F Specifications
• 4118 Specifications
• 2218 Specifications
M20F Specifications
Refer to the following tables for the M20F specifications:
• Table 1 General Specifications.
• Table 2 Printer Specifications.
• Table 3 Facsimile Specifications (M20i).
• Table 4 Scanner Specifications.
• Table 5 Copy Specifications.
• Table 6 Telephone Specifications (M20i).
• Table 7 Consumables.
• Table 8 Fuser Operating Temperatures.
• Table 9 HVPS Output.
Table 1 General specifications
Item Description
Type of Unit Desktop
Operation System Win98/ME/ NT 4.0/2000/XP
Duplex Printing Yes(Default)
Printing Speed Simplex: 22ppm for 8.5x11, 21ppm for A4
Duplex: 13ppm for 8.5x11, 12.6ppm for A4
Interface IEEE1284 (ECP)
USB (without HUB mode)
CPU 120 MHz (ARM946ES)
System Memory 32Mb
Warming up Time 30 Sec (Power on), 25 Sec from sleep mode
Absolute Storage Condition Temperature: -20°C to 40°C, Humidity: 10% RH to 90% RH
Operating Condition Temperature: 10°C to 32°C, Humidity: 20% RH to 80% RH
Recommended Operating Con-
dition
Temperature: 16°C to 30°C, Humidity: 30% RH to 70% RH
Dimension(W X D X H) 560 X 433 X 397 mm (Platen cover attached)
560 X 433 X 490 mm (DADF attached)
560 X 433 X 530 mm (SCF attached)
560 X 433 X 620 mm (both DADF and SCF attached)
Weight About 26Kg (with CRU)
Acoustic Noise Less than 65 dB (Copy/Printing scanning mode)
Power Rating AC 100VAC to 127VAC +/- 15%, 50/60Hz +/- 3Hz
AC 220VAC to 240VAC +/- 15%, 50/60Hz +/- 3Hz
