December 2006
6-34
WorkCentre M20, 4118, FaxCentre 2218 Family
GP 11
General Procedures and Information
The environment acronyms are as follows:
• LL - Low temperature/low humidity.
• NN - Normal temperature/normal humidity.
• HH - High temperature/high humidity.
4118 Specifications
Refer to the following tables for the 4118 specifications:
• Table 10 General Specifications.
• Table 11 Printer Specifications.
• Table 12 Facsimile Specifications (4118X).
• Table 13 Scanner Specifications.
• Table 14 Copy Specifications.
• Table 15 Telephone Specifications (4118X).
• Table 16 Consumables.
• Table 17 Fuser Operating Temperatures.
• Table 18 HVPS Output.
Drum Cartridge 20,000 sheets
(simplex normal mode)
Table 8 Fuser operating temperatures
Machine State or Paper
Type
Environment (1st print-5 min / 5 min-10 min / 10 min +)
LL NN HH
Machine in standby 170 deg C 170 deg C 165 deg C
Plain 187/183/178 deg C 185/178/173 deg C 175/170/165 deg C
Thick 200/195/195 deg C 195/190/190 deg C 195/190/190 deg C
OHP 175 deg C 165 deg C 165 deg C
Thin 185/180/175 deg C 180/180/175 deg C 180/175/170 deg C
Cardstock 204/200/200 deg C 204/200/200 deg C 200/195/195 deg C
Envelope 200/195/195 deg C 195/190/190 deg C 190/190/190 deg C
Table 9 HVPS Output
HVPS Output Voltage
Transfer High Voltage (THV) Max +5000V DC +/- 10%
Transfer Cleaning Voltage (THV Neg) -1000V DC +/- 15%
Developing Voltage (DEV) -450V to -500V DC +/- 5%
Charge Voltage (MHV) -1300V to -1450V DC +/- 5%
Supply Voltage -400V to -650V DC +/- 5%
Blade Voltage -300V to -550V DC +/- 5%
OPC Drum -135V +/- 15%
Table 7 Consumables
Item Life expectancy
Table 10 General specifications
Item Description
Type of Unit Desktop
Operation System Win98/ME/ NT 4.0/2000/XP
Mac OS 10.3-Linux
Duplex Printing Yes
Printing Speed Simplex: 18ppm for 8.5x11, 17ppm for A4
Duplex: 10ppm for 8.5x11, 9.5ppm for A4
Interface IEEE1284 (ECP)
USB 2.0
CPU 240 MHz(ARM920T)
System Memory 64Mb
Warming up Time 30 Sec (Power on), 25 Sec from sleep mode
Absolute Storage Condition Temperature: -20°C to 40°C, Humidity: 10% RH to 90% RH
Operating Condition Temperature: 10°C to 32°C, Humidity: 20% RH to 80% RH
Recommended Operating Con-
dition
Temperature: 16°C to 30°C, Humidity: 30% RH to 70% RH
Dimension (W X D X H) 560 X 433 X 397 mm (platen cover attached)
560 X 433 X 490 mm (ADF attached)
560 X 433 X 530 mm (SCF attached)
560 X 430 X 595mm (both ADF and SCF attached)
Weight About 26Kg (with CRU)
Acoustic Noise Less than 65 dB (Copy/Printing scanning mode)
Power Rating AC 100VAC to 127VAC +/- 15%, 50/60Hz +/- 3Hz
AC 220VAC to 240VAC +/- 15%, 50/60Hz +/- 3Hz
Power Consumption Avg. 450W (Print/Copy)
Power Save Consumption Avg. 28W
Recommended System
Requirement
Pentium IV 1.2 Ghz, 128 MB RAM, 220MB (Hard Disk)
Minimum System Requirement Pentium III 500Mhz, 32 MB RAM, 100MB (Hard Disk)
LCD 20 characters X 2 lines
Memory 16 Mbyte for flash Memory, 64 Mbyte SDRAM
