December 2006
6-38
WorkCentre M20, 4118, FaxCentre 2218 Family
GP 11
General Procedures and Information
The environment acronyms are as follows:
• LL - Low temperature/low humidity.
• NN - Normal temperature/normal humidity.
• HH - High temperature/high humidity.
Table 26 Fuser operating temperatures
Machine State or Paper
Type
Environment (1st print-5 min / 5 min-10 min / 10 min +)
LL NN HH
Machine in standby 170 deg C 170 deg C 165 deg C
Plain 187/183/178 deg C 185/178/173 deg C 175/170/165 deg C
Thick 200/195/195 deg C 195/190/190 deg C 195/190/190 deg C
OHP 175 deg C 165 deg C 165 deg C
Thin 185/180/175 deg C 180/180/175 deg C 180/175/170 deg C
Cardstock 204/200/200 deg C 204/200/200 deg C 200/195/195 deg C
Envelope 200/195/195 deg C 195/190/190 deg C 190/190/190 deg C
Table 27 HVPS Output
HVPS Output Voltage
Transfer High Voltage (THV) +1300V +/- 20V
Transfer Cleaning Voltage (THV Neg) -1000V +300V/-150V
Developing Voltage (DEV) -450V +/- 20V
Charge Voltage (MHV) -1350V +/- 50V
Supply Voltage -600V +/- 50V
Blade Voltage -500V +/- 20V
OPC Drum -135V +/- 15%
