Yamaha 60F - Page 100

6-7
E
LOWR
DISASSEMBLY
12) Forward gear bearing outer race
Å For USA and Canada
ı Except for USA and Canada
NOTE:
For ease of reassembly and adjustment,
keep shim packs in their groups as
removed.
Slide hammer set:
YB-6096.................................. 1
Bearing outer race puller:
90890-06523........................... 2
Å
1
ı
2
13) Drive shaft bearing outer race
Å For USA and Canada
ı Except for USA and Canada
Slide hammer set:
YB-6096.................................. 1
Stopper guide plate:
90890-06501........................... 2
Bearing puller:
90890-06535........................... 3
Stopper guide stand:
90890-06538........................... 4
Å
1
ı
2
3
4
14) Drive shaft sleeve
15) Drive shaft needle bearing
Driver rod:
YB-6071/90890-06602 ........... 1
Needle bearing attachment:
YB-6155/90890-06611 ........... 2
1
2
