8-13
–+
ELEC
E
REMOVAL
M40003-0
REMOVAL
MAGNETO BASE
1. Remove the flywheel cover.
2. Remove the starter-pulley.
3. Loosen the flywheel nut until it is flush
with the crankshaft.
CAUTION:
The major load must be carried in the direc-
tion of the arrows. If not, the holder may
easily slip off.
Flywheel holder:
YB-6139/90890-06522
CAUTION:
Keep the nut side flush with the crankshaft
end until the flywheel comes off the
tapered portion of the crankshaft.
To Next Page
