8-14
–+
ELEC
E
REMOVAL
4. Remove the flywheel magneto.
Flywheel puller:
YB-6117/90890-06521
YB-6117
CAUTION:
To prevent damage to the engine or tools,
screw in the flywheel magneto-puller set-
bolts evenly and completely so that the
puller plate is parallel to the flywheel.
5. Remove the woodruff key from the
crankshaft keyway using a screwdriver.
CAUTION:
Take special care not to damage the sur-
face of the crankshaft. When removing the
flywheel magneto, lift it up while tilting it
slightly. Do not allow the magneto to con-
tact the timing plate.
