8-29
–+
ELEC
E
ELECTRICAL ANALYSIS
M58800-0
BRACKET
1. Inspect the bracket and replace it if it’s
cracked.
50, 60, 70 hp 75, 80, 90 hp
M58900-0*
BATTERY
Refer to “PERIODIC SERVICE” section
in chapter 3.
M59000-0
ENGINE STOP SWITCH
(P60TH/60FEHTO, P75TH/75CEHTO,
90AEHD)
1. When removing and installing the lock-
plate, check for continuity according to
the chart below.
Lock plate
Wire color
WB
Removed
Installed
