6-29
E
LOWR
INSTALLATION
170003-0*
INSTALLATION
1. Check that the clutch dog shifts to “For-
ward”, “Neutral” and “Reverse” cor-
rectly by turning the shift rod, and shift
into “Neutral”.
Shift rod wrench:
YB-6052
2. Align the mark on the shift lever with
the arrow mark on the bottom cowling.
3. Grease the spline of the drive-shaft and
the water-tube outer face, align the
water-tube and drive-shaft, install the
lower unit and tighten the bolts to the
specified torque.
T
R
.
.
Lower unit mounting bolts:
40 Nm (4.0 m • kg, 29 ft • lb)
