BRACKET UNIT
K20002-0
REMOVAL
1. Remove the power-head.
2. Remove the swivel-bracket from the
upper casing.
CAUTION:
Lay the outboard motor on the floor to
carry out this removal.
DISASSEMBLY
1. Referring to the exploded diagram, dis-
assemble the bracket unit.
INSPECTION
ANODE
1. Check anode and replace with new one
when the size is less than 1/3 of original
length.
BRACKET
1. Inspect the bracket and replace them, if
cracked.
TRIM SENSOR
1. Check resistance of the new trim
sensor.
2. Measure resistance between black and
pink leads to check that the value
changes gradually in the whole trim
and tilt range. If not, replace trim sensor
with new one.
Trim sensor resistance:
Pink – Black
360 ~ 540 Ω
Black – Orange
800 ~ 1200 Ω
