2-9
SPEC
E
MAINTENANCE SPECIFICATIONS
Commutator outside
diameter
mm (in) 30 (1.18) 33 (1.30)
<Repair limit> mm (in) 29 (1.14) 31 (1.22)
Pinion/ring gear gap mm (in) 3.0 ~ 5.0 (0.12 ~ 0.20)
Others:
Electrothermal valve
resistance [20°C (68°F)]
Ω 2.3 ~ 3.5 (L – B)
Fuel enrichment valve
resistance [20°C (68°F)]
Ω 3.4 ~ 4.0 (L – B)
Trim sensor resistance Ω 360 ~ 540 (P – B)
800 ~ 1,200 (B – O)
Fuse A 20
Item Unit
Model
50hp 60hp 70hp 75hp 80hp 90hp
