Yamaha F40BWHD - Removing the Drive Shaft; Removing the Drive Shaft Bearing

LOWR
6-15
DRIVE SHAFT
E
REMOVING THE DRIVE SHAFT
1. Re m ov e:
• Oil seal housing
• Pinion gear nut
2. Remove:
• Drive shaft assembly
•Pinion gear
REMOVING THE DRIVE SHAFT
BEARING
Remove:
• Drive shaft bearing
A
For USA and Canada
B
Except for USA and Canada
1
3
2
Drive shaft holder .........................
YB-06079/90890-06517
Pinion nut holder ..........................
YB-06078/90890-06505
Pinion nut holder attachment .....
90890-06506
1
2
3
1
A
2
B
Bearing separator .........................
YB-06219/90890-06534
Bearing/oil seal attachment ........
90890-06641
1
2
