LOWR
6-7
PROPELLER SHAFT HOUSING ASSEMBLY
E
PROPELLER SHAFT HOUSING ASSEMBLY
REMOVING/INSTALLING THE PROPELLER SHAFT HOUSING ASSEMBLY
4
3
2
1
A
A
16 Nm(1.6 m kgf, 12 ft lb)
8 25 mm
LT
572
Order Job/Part Q’ty Remarks
Gear oil Refer to "CHANGING AND CHECKING
THE GEAR OIL" on page 3-19.
Shift rod assembly Refer to "SHIFT ROD ASSEMBLY" on
page 6-6.
1Bolt 2
2 Propeller shaft housing 1
3Washer 1
4 Propeller shaft 1
For installation, reverse the removal
procedure.
To Next Page
