Yamaha F40BWHD - Charging System (WHD, ED, ET)

–+
ELEC
8-29
CHARGING SYSTEM (WHD, ED, ET)
E
CHARGING SYSTEM (WHD, ED, ET)
1
4
2
5
3
Y
Y
Y
Y
R
R
B
1.25R
1.25R
1
Lighting coil
B: Black
2
Rectifier/regulator
R: Red
3
Fuse (20 A)
Y : Yellow
4
Starter relay
5
Battery
