Yamaha F40BWHD - Removing;Installing the Power Unit

POWER UNIT
5-14
E
POWR
REMOVING/INSTALLING THE POWER UNIT
1
2
3
4
5
21 Nm(2.1 m kgf,15ft lb)
8 80 mm
6 16 mm
6 25 mm
8 12 mm
572
Order Job/Part Q’ty Remarks
1 Oil level gauge 1
2 Apron 1
3 Power unit 1
4 Dowel pin 2
5 Upper casing gasket 1
Not reusable
For installation, reverse the removal
procedure.
