WATER PUMP
6-4
E
LOWR
WATER PUMP
REMOVING/INSTALLING THE WATER PUMP
4 8 mm
8 30 mm
Order Job/Part Q’ty Remarks
1 Plastic collar 1
2 Rubber spacer 1
3Bolt 4
4 Water pump housing 1
5O-ring 1
Not reusable
6 Insert cartridge 1
7 Impeller 1
8 Woodruff key 1
9 Impeller plate 1
10 Gasket 1
Not reusable
11 Dowel pin 2
For installation, reverse the removal
procedure.
