Yamaha F40BWHD - Power Trim and Tilt Motor (ET)

–+
ELEC
8-37
POWER TRIM AND TILT MOTOR (ET)
E
POWER TRIM AND TILT MOTOR (ET)
DISASSEMBLING/ASSEMBLING THE POWER TRIM AND TILT MOTOR
1
2
3
9
8
7
6
4
6
7
5
7
6
10
6
7
9
5
10
11
Order Job/Part Q’ty Remarks
1 Screw 2
2 Stator 1
3 O-ring 1 49.5×2.0 mm
4 Screw 2
5 Brush holder 1
6 Brush 2
7 Brush spring 2
8 Screw 1
9 Armature 1
10 Power trim and tilt motor base 1
11 O - r i n g 1
Not reusable
For assembly, reverse the disassembly
procedure.
Not reusable
