STARTER MOTOR
8-28
E
–+
ELEC
2. Check:
• Brush assembly continuity
Out of specification → Replace the
brush assembly.
1
5
4
3
2
Brush assembly continuity
Brush - Brush
Brush - Brush
Brush ( , ) -
Brush assembly holder
Continuity
Brush - Brush
Brush - Brush
Brush - Brush
Brush - Brush
Brush ( , ) -
Brush assembly holder
No continuity
1 2
3 4
3 4
5
1 3
1 4
2 3
2 4
1 2
5
