MAINTENANCE SPECIFICATIONS
2-13
E
SPEC
Symbol
Unit
Model
Worldwide F40BMHD, WHD F40BED, F40BET
USA,
Canada
F40MSH, F40MLH F40ESR, F40TLR
L1 mm (in) 568.7 (22.4)
L2 mm (in) 233.6 (9.2) 131.6 (5.1)
L3 mm (in) 762.8 (30.0) —
L4 mm (in) 521.3 (20.5)
L6 (S) mm (in) 813.5 (32.0) 813.2 (32.0)
(L) mm (in) 922.9 (36.3) 922.3 (36.3)
(X) mm (in) 1024.2 (40.3) 1023.2 (40.3)
L7 mm (in) 383.0 (15.1) 353.2 (14.0)
H1 (S) mm (in) 753.1 (30.0)
(L) mm (in) 876.3 (34.5)
(X) mm (in) 990.3 (40.0)
H2 mm (in) 492.8 (19.4) 464.1 (18.2)
H3 mm (in) 175 (6.8)
H4 (S) mm (in) 410.1 (16.1)
(L) mm (in) 533.3 (21.0)
(X) mm (in) 647.3 (25.5)
H6 (S) mm (in) 604.1 (24.0) 599.8 (23.6)
(L) mm (in) 670.8 (26.4) 665.7 (26.2)
(X) mm (in) 732.5 (28.8) 726.7 (28.6)
H7 mm (in) 293.4 (11.5) 285.7 (11.2)
H8 mm (in) 43.2 (1.7) 42.4 (1.6)
H9 mm (in) 727.3 (28.6) 708.0 (28.0)
W1 mm (in) 188.9 (7.4)
W5 mm (in) 312.6 (12.3)
W6 mm (in) 687.1 (27.0)
—
A1 Degree 40
A2 Degree 62.7 62.3
(Shallow water) Degree 29 - 43 —
A3 Degree 4 4
