11-15
11
11-5 Communication Command Description
COMMUNICATION WITH PC
(18)
@ACHA <axis>, <position>
Defines an arch motion by setting a position.
Axis : Specify the axis that performs an arch motion. "1" for the X-axis
and "2" for the Y-axis.
Position : This is the position (absolute position with respect to the origin)
the arch motion axis moves to. The setting range is from -9999 to
9999 mm.
Transmission example : @ACHA 2, 10 c/r l/f .................... Defines an arch motion in
which the Y-axis temporarily
returns to Y=10.00.
Response example : OK c/r l/f
(19)
@ACHI <axis>, <distance>
Defines an arch motion by setting a distance.
Axis : Specify the axis that performs an arch motion. "1" for the X-axis
and "2" for the Y-axis.
Distance : This is the distance (relative distance with respect to the current
position) the arch motion axis moves. The setting range is from -
9999 to 9999 mm.
Transmission example : @ACHI 2, -100 c/r l/f .................. Defines an arch motion in
which the Y-axis temporarily
returns a distance of -100.00.
Response example : OK c/r l/f
c
CAUTION
When movement is interrupted with a stop (^C) statement, the current position in the program stays unchanged
so that the movement can be resumed by re-executing the movement command. However, if the command is
reset, the current position in the program is initialized to the robot position.
(20)
@DO <general-purpose output or memory output number>,<output status>
Turns a general-purpose output or memory output on or off.
Output number : Specify one of the general-purpose outputs from 0 to 12 (13
points) or one of the memory outputs from 100 to 131 (32
points).
Output status : Specify 1 (ON) or 0 (OFF).
Transmission example : @DO 3,1 c/r l/f............................. Turns on general-purpose
output 3.
Response example : OK c/r l/f
