SWINGARM
4-56
● Oil seal “2”
●
Spacer “3”
(to the swingarm “4”)
3. Install:
● Rear shock absorber assembly
●
Rear wheel
Refer to “REAR SHOCK ABSORBER AS-
SEMBLY” on page 4-51 and “REAR WHEEL”
on page 4-8.
4. Adjust:
●
Drive chain slack
Refer to “ADJUSTING THE DRIVE CHAIN
SLACK” on page 3-20.
Installed depth “a”
3 mm
Drive chain slack
40.0–45.0 mm (1.57–1.77 in)
a a
2
2
3
4
1
