LUBRICATION POINTS AND LUBRICANT TYPES
2-18
EAS20360
LUBRICATION POINTS AND LUBRICANT TYPES
EAS20370
ENGINE
Lubrication point Lubricant
Oil seal lips
All O-rings
All bearing retainers
Seat surface of cylinder head bolt (226 mm)
Threaded portion of cylinder head bolt (226 mm)
Cylinder inner surface
Crankshaft pin surface
Thrust end surface of connecting rod big end
Piston pin surface
Piston surface
Buffer boss surface
Valve stem (intake/exhaust)
Valve stem end (intake/exhaust)
Rocker arm shaft surface (intake/exhaust)
Camshaft profile
Rocker arm inner surface (intake/exhaust)
Inside of oil pump assembly
Oil pump gasket
Starter clutch idle gear 1
Starter clutch idle gear 2
Starter clutch gear
Clutch push rod surface, and surface end
Adjusting screw surface, and surface end (push lever)
Primary driven gear (clutch housing)
Push lever shaft surface
LS
LS
E
E
M
E
E
E
E
E
E
M
M
E
M
M
E
LS
E
E
E
LS
LS
E
E
