Before troubleshooting, remove the following part(s):
1.Seat
2.Rear side cover
3.Tool box
4.Fuel tank
5.Carburetor assembly
6.Rectifier/regulator
1. Check the fuse.
Refer to “CHECKING THE FUSE” on
page 7-37
.
NG→ Replace the fuse(s).
OK↓
2. Check the battery.
Refer to
“CHECKING AND CHARG-
ING THE BATTERY” on page 7-37.
NG→
● Clean the battery terminals.
●
Recharge or replace the battery.
OK↓
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 7-33.
NG→ Replace the main switch.
OK↓
4. Check the thermo switch.
Refer to
“CHECKING THE THERMO
SWITCH” on page 7-46.
NG→ Replace the thermo switch.
OK↓
5. Check the carburetor warmer.
Refer to “CHECKING THE CARBURE-
TOR WARMER” on page 7-47.
NG→ Replace the carburetor warmer.
OK↓
6. Check the entire carburetor heating
system’s wiring.
Refer to
“CIRCUIT DIAGRAM” on page
7-25
.
NG→
Properly connect or repair the carburetor
heating system’s wiring.
OK↓
This circuit is OK.
To Next Page
