LUBRICATION POINTS AND LUBRICANT TYPES
2-19
EAS20380
CHASSIS
Ball surface (clutch push rod)
Main axle assembly
Drive axle assembly
Shift fork guide bar
Shift drum assembly
Shift shaft assembly
Shift pedal (bolt mount inner surface)
Crankcase mating surface
Yamaha bond No.
1215 (Three Bond
No. 1215®)
Threaded portion of starter motor bolt
Yamaha bond No.
1215 (Three Bond
No. 1215®)
Lubrication point Lubricant
LS
M
M
E
E
E
LS
Lubrication point Lubricant
Upper bearings and oil seal lip (steering head)
Lower bearings and oil seal lip (steering head)
Front wheel oil seal lip (left/right)
Rear wheel oil seal lip (left/right)
Brake pedal bolt shaft
Throttle grip and throttle cable end
Throttle cable housing inner surface
Brake lever bolt shaft
Brake lever and front brake master cylinder moving parts
Adjusting screw end (brake lever)
Rear brake master cylinder pushrod (boot mount groove)
Brake caliper piston seal
Brake caliper support bolt shaft
Brake pad support bolt shaft
LS
LS
LS
LS
LS
LS
LS
S
S
S
S
S
S
S
