Voltage
System voltage 12 V
Ignition system
Ignition system CDI
Advancer type Digital
Ignition timing (B.T.D.C.) 10.0 °/1400 r/min
CDI
Magneto model/manufacturer F5XT/YAMAHA
Pickup coil resistance 248–372 Ω (Red–white)
CDI unit model/manufacturer 3C5/YAMAHA
Ignition coil
Model/manufacturer 2JN/YAMAHA
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 0.18–0.28 Ω
Secondary coil resistance 6.32–9.48 kΩ
Spark plug cap
Material Resin
Resistance 10.0 kΩ
AC magneto
Model/manufacturer F5XT/YAMAHA
Standard output 14.0 V, 190 W@5000 r/min
Stator coil resistance 0.688–1.032
Ω (White–white)
Rectifier/regulator
Regulator type Semi conductor-short circuit
Model/manufacturer SH629A-12/SHINDENGEN
No load regulated voltage 14.1–14.9 V
Rectifier capacity 10.0 A
Withstand voltage 200.0 V
Battery
Model YTZ7S
Voltage, capacity 12 V, 6.0 Ah
Specific gravity 1.310
Manufacturer GS YUASA
Ten hour rate amperage 0.60 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60 W/55.0 W × 1
Tail/brake light 12 V, 8.0 W/27.0 W × 1
Front turn signal/position light 12 V, 27 W/5.0 W × 2
Rear turn signal light 12 V, 27.0 W × 2
License plate light 12 V, 8.0 W × 1
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
High beam indicator light LED
