Electric starting system
System type Constant mesh
Starter motor
Model/manufacturer 3C5/YAMAHA
Power output 0.40 kW
Armature coil resistance 0.0126–0.0154 Ω
Brush overall length 10.0 mm (0.39 in)
Limit 3.50 mm (0.14 in)
Brush spring force 5.52–8.28 N (19.87–29.80 oz) (563–844 gf)
Commutator diameter 22.0 mm (0.87 in)
Limit 21.0 mm (0.83 in)
Mica undercut (depth) 1.50 mm (0.06 in)
Starter relay
Model/manufacturer 2768096-A/JIDECO
Amperage 180.0 A
Coil resistance 4.18–4.62 Ω
Horn
Horn type Plane
Quantity 1 pcs
Model/manufacturer HF-12/NIKKO
Maximum amperage 3.0 A
Coil resistance 1.01–1.11 Ω
Performance 108–116 dB/2m
Turn signal relay
Relay type Full transistor
Model/manufacturer FE218BH/DENSO
Built-in, self-canceling device No
Turn signal blinking frequency 75–95 cycles/min
Starting circuit cut-off relay
Model/manufacturer ACM33211 M04/MATSUSHITA
Coil resistance 86.4–105.6 Ω
Carburetor warmer resistance 4.7–9.5 W 20°C (68°F)
Fuses
Main fuse 20.0 A
Spare fuse 20.0 A
