TIGHTENING TORQUES
2-15
EAS20350
CHASSIS TIGHTENING TORQUES
Clutch boss nut M16 1 75 Nm (7.5 m•kg, 54 ft•lb)
lock
washer
use
Clutch spring bolt M6 5 8 Nm (0.8 m•kg, 5.8 ft•lb)
Lock nut (Push lever adjusting
screw)
M6 1 8 Nm (0.8 m•kg, 5.8 ft•lb)
Push lever holding bolt M8 1 12 Nm (1.2 m•kg, 8.7 ft•lb)
Drive sprocket nut M18 1 110 Nm (11.0 m•kg, 80 ft\•lb)
lock
washer
use
Stopper lever bolt M6 1 10 Nm (1.0 m•kg, 7.2 ft•lb)
Neutral switch M10 1 20 Nm (2.0 m•kg, 15 ft•lb)
Starter motor bolt M6 2 10 Nm (1.0 m•kg, 7.2 ft•lb)
Pickup coil bolt M6 2 10 Nm (1.0 m•kg, 7.2 ft•lb)
Stator assembly bolt M6 3 10 Nm (1.0 m•kg, 7.2 ft•lb)
Item
Threa
d size
Q’ty Tightening torque Remarks
LT
LT
LT
Item
Threa
d size
Q’ty Tightening torque Remarks
Engine mounting nut M10 3 60 Nm (6.0 m•kg, 43 ft•lb)
Engine bracket nut M8 2 44 Nm (4.4 m•kg, 32 ft•lb)
Down tube nut M10 5 60 Nm (6.0 m•kg, 43 ft•lb)
Drive chain tensioner bolt M8 1 23 Nm (2.3 m•kg, 17 ft•lb)
Mudguard bolt M6 2 7 Nm (0.7 m•kg, 5.1 ft•lb)
Front fender bolt M6 4 7 Nm (0.7 m•kg, 5.1 ft•lb)
Grab bar bolt M8 4 23 Nm (2.3 m•kg, 17 ft•lb)
Rear side cover bolt M6 2 9 Nm (0.9 m•kg, 6.5 ft•lb)
Tool box bolt M6 3 7 Nm (0.7 m•kg, 5.1 ft•lb)
Horn bracket bolt M6 1 10 Nm (1.0 m•kg, 7.2 ft•lb)
Battery/Electrical box bolt M6 3 7 Nm (0.7 m•kg, 5.1 ft•lb)
Rectifier/regulator bolt M6 2 7 Nm (0.7 m•kg, 5.1 ft•lb)
Starter motor lead bolt M6 1 7 Nm (0.7 m•kg, 5.1 ft•lb)
Ignition coil bolt M6 2 7 Nm (0.7 m•kg, 5.1 ft•lb)
Pivot shaft nut M12 1 80 Nm (8.0 m•kg, 58 ft•lb)
Rear shock absorber assembly
upper nut
M12 2 50 Nm (5.0 m•kg, 36 ft•lb)
