Yamaha XT250X - FRONT WHEEL

FRONT WHEEL
4-2
EAS21870
FRONT WHEEL
Removing the front wheel and brake disc
Order Job/Parts to remove Q’ty Remarks
NOTE:
Use a suitable stand to raise the front wheel
off the ground.
1 Front wheel axle nut 1
2 Front wheel axle 1
3 Front wheel assembly 1
4 Collar/dust seal 2/2
5 Front brake disc 1
For installation, reverse the removal proce-
dure.
LT
T
R
.
.
10 Nm (1.0 m • kg, 7.2 ft • Ib)
T
R
.
.
85 Nm (8.5 m • kg, 62 ft • Ib)
1
2
3
4
4
5
(6)
