● Tighten the lower ring nut with the specified torque (38 Nm (3.8 m•kg, 28 ft•lb)).
● Check the front fork leg operates smoothly by turning it to the right and left.
● Loosen the lower ring nut completely and retighten it with the specified torque (4 Nm (0.4 m•kg, 2.9
ft•lb)).
Rear brake disc bolt M8 3 28 Nm (2.8 m•kg, 21 ft•lb)
Front brake master cylinder
holder bolt
M6 2 7 Nm (0.7 m•kg, 5.1 ft•lb)
Front brake lever nut M6 1 7 Nm (0.7 m•kg, 5.1 ft•lb)
Rear brake hose joint (caliper
side)
M10 1 26 Nm (2.6 m•kg, 19 ft•lb)
Rear brake hose joint (hose side) M10 1 14 Nm (1.4 m•kg, 10 ft•lb)
Rear brake pad support bolt M10 2 17 Nm (1.7 m•kg, 12 ft•lb)
Item
Threa
d size
Q’ty Tightening torque Remarks
LT
