CRANKCASE
5-55
Removing the Bearing
Order Job/Parts to remove Q’ty Remarks
Crankshaft assembly
Refer to “CRANKSHAFT ASSEMBLY” on
page 5-58.
Main axle assembly/Drive axle assembly Refer to “TRANSMISSION” on page 5-61.
1 Bearing retainer 1
2 Oil seal 2
3 Bearing 7
For installation, reverse the removal proce-
dure.
E
E
E
E
E
LT
LT
New
New
T
R
.
.
10 Nm (1.0 m • kg, 7.2 ft • Ib)
3
3
3
3
2
2
1
3
3
3
To Next Page
