REAR WHEEL
4-9
Disassembling the rear wheel
Order Job/Parts to remove Q’ty Remarks
1 Oil seal 2
2 Wheel bearing 3
3 Spacer 1
For installation, reverse the removal proce-
dure.
1
2
3
1
2
New
New
