B95W
Maintenance
06_Wartung und Pflege_en.fm - V1.0 - 1.8.17
123 / 306
6
20
The intervals stated are valid for single-shift operation.
Tab. 6-4 Lubrication schedule
Danger of slipping
Floor may be slippery due to oil spillage
Z Finally, clean any oil from the floor.
Loc. Lubricating point
Quantity Every
day
Weekly Page
1 Bucket rod - Quick-attach system 1 X --
2 Quick-attach system 1 X --
3 Bucket cylinder - bucket rod - tilt lever 3 X --
4 Dipperstick - Quick-attach system 1 X --
5 Dipperstick - tilt lever 1 X --
6 Bucket cylinder - dipperstick 1 X --
7 Intermediate boom - dipperstick 1 X --
8 Dipperstick cylinder - dipperstick 1 X --
9 Intermediate boom cylinder - intermediate boom 2 X --
10 Dipperstick cylinder - intermediate boom 1 X --
11 Intermediate boom - boom 1 X --
12 Boom cylinder- boom 1 X --
13 Intermediate boom cylinder - boom 2 X --
14 Slewing column - boom 1 X --
15 Boom cylinder - slewing column 1 X --
18 Uppercarriage - Slewing column 2 X --
19 Support leg - undercarriage 2 X --
20 Support cylinder - undercarriage 2 X --
21 Support cylinder - support leg 2 X --
22 Support leg – rear support blades/pads 2 X --
24 Pendulum bearing rear/front for front axle 2 X --
25 Slewing ring – bearing races 1 X 188
26 Slewing ring – toothing 1 X 188
27 Articulated cylinder – uppercarriage
(center wall at slewing
column)
1X--
28 Articulated cylinder – slewing column 1 X --
29 Hood hinges 2 X --
30 Steering housing each 2 X --
31 Hinges for maintenance cover/maintenance ladder 2 X --
Special equipment
34 Clamshell grabs 11 X --
35 Slew bucket 2 X --
36 Hydraulic cylinders of swing bucket 2 X --
