B95W
Maintenance
142 / 306
6
06_Wartung und Pflege_en.fm - V1.0 - 1.8.17
20
6.7.4 Air intake system
Fig. 6-9 Air filter maintenance
1 Filter element
Preparing machine for maintenance
Position upper carriage out of travel direction approx. 75° to the right.
Position the work attachment in line with the uppercarriage and lower it onto
the ground.
Shut down the engine.
Open the engine hood.
You can change the air filter cartridge (1) while standing on the ground.
Danger posed by dust being drawn into the engine
There is a risk of the engine taking in dirty air and
sustaining serious damage.
Z All maintenance work on the air intake system must be
carried out with the engine shut down.
Z Do not start the engine after the filter cartridge has been
removed.
Z Only install filter cartridges that are in perfect condition.
Z Only use brushes with synthetic or natural bristles.
Z Ensure that everything is spotless. Close suction openings.
