Yanmar B95W - Excavator Equipment; Brakes

B95W
Technical data
280 / 306
9
09_Technische Daten_en.fm - V1.0 - 1.8.17
29
9.2.6 Excavator equipment
Tab. 9-8 Excavator equipment
*Data are theoretical values as per DIN 24086
9.2.7 Brakes
Tab. 9-9 Brakes
Description
Unit GA with
LS 2000
GA with
LS 2200
Circular Mono
with
adjustable
Digging depth mm 4080 4280 4030 3910
Max. dump height mm 5400 5600 3550 4035
Maximum height of bucket
hinge point
mm 6450 6635 5980 5070
Max. reach mm 7580 7815 8090 7950
Bucket angle of rotation ° 187 187 187 187
Tear resistance N 42 600 36 000 42 000 42 600
*Breakaway torque N 53 200 53 200 53 200 53 200
Brakes
Service brake Hydraulic pump accumulator two-circuit brake
B95W, B95W S
Oil-immersed multi-disk brake in the middle housing of the
front axle and by the rear axle’s wheel hub
B95W AL
Oil-immersed multi-disk brake in the middle housing of the
front axle and rear axles
Excavator brake Operating brake locking mechanism that acts on all
4 wheels
Parking brake Hydraulic, internal spring-loaded brake effective on the
multiple disk brake in the front axle, electrically activated.
Additional brake The hydrostatic travel drive in closed circuit additionally
acts as an additional non-wearing auxiliary brake.
Slewing brake The hydrostatic swing motor acts as a wear-free swing
brake.
The locking takes place automatically via a transmission-
integrated hydraulic spring-applied disk brake that may be
unlocked.
